McHale Fusion Vario Baler & Wrapper
10
2.2 Front view
No. Machine function
1 Hydraulic section (inside cover)
2 Stop switch B (inside cover)
3 Netter unit
4 Chamber door pressure clock
5 Drawbar & stand
6 Crop guard or crop roller
7 Chopper unit
8 Pick-up reel
9 Wheel chocks
10 Knife blanks (inside cover)
11 Spare film section (inside cover)
12 Net tension pump
1
2
3
4
678 910
5
11
12
