McHale Issue 5 - Machine Specifications; Tyre Specifications

McHale Fusion Vario Baler & Wrapper
13
2.6 Machine specifications
2.7 Tyre specifications
Bale chamber diameter (Baling & Wrapping) 1.1 - 1.5 m (43.3 - 59”)
Bale chamber diameter (Baling only) 1.0 - 1.65 m (39.4 - 65”)
Bale chamber width 1.23 m (48”)
Pick-up width 2.10 m (83”)
Net wrap
Net width Max. 1.26 m (49.6”)
Max. roll weight 40 kg (See warning below)
Dispenser film
Film width 750 mm (29.5”)
Film stretch 70% (64% & 55% optional)
Film layers 2+2; 2+2+2; etc.
Film storage 12 rolls (+ 2 rolls on dispensers)
Dispenser rotary speed Max. 36 rpm
CAUTION: Heavy net rolls should be handled by two people
Pay attention to the heavy weight of the net roll. It is recommended that
full net rolls should be handled by two people.
Details Type
Field
pressure
Road
pressure
Part No.
650/50R22.5 157 D (Vredestein) Flo-Pro 1.65 bar 3.2 bar CWH00054
650/55R22.5 163 D (Alliance) A-885 1.65 bar 4 bar CWH00290
680/50R22.5 157 D (Vredestein) Flo-Trac 1.65 bar 2.8 bar CWH00281
170/60-8 71 A8 (Vredestein) Pick-up 2.07 bar 2.07 bar CWH00037
