McHale Fusion Vario Baler & Wrapper
52
6.6 Chopper unit knife removal & installation
Knife installation/removal should be carried out in the following way:
Baling position Netting position
CAUTION: Ensure knives are installed correctly
Incorrectly installed knives can cause irreparable damage to both the
knives and the rotor, leading to serious destruction within the machine!
CAUTION: Use protective gloves
Use protective gloves for any manual work in this area! The number of
knives installed determines the cut length of the material.
1. Ensure the knives are in the up/on position, before beginning.
2. Lower the chopper-unit floor half way. Open the chamber door to the fully-up
position.
3. Using the lever valve (A), lock the chamber door in position, by pulling it towards
you and then rotating it 90° to the left vertical position, as shown.
