McHale Fusion Vario Baler & Wrapper
11
2.3 Rear view
No. Machine function
1 Hose carrier
2 Chamber door/tailgate
3 Spare film section (inside cover)
4 Dispenser ring
5 Dispenser
6 Tip arm roller
7 Cut & hold unit
8 Stop switch A
9 Dispenser access door
10 Drive side
11 Platform
1
2345
78910 6
11
