McHale Fusion Vario Baler & Wrapper
128
10.16.5 Rotor duplex chain adjustment
To adjust the duplex chain the following tools are required; two 24 mm spanners.
1. Hold the lower nut and loosen the upper nut.
2. To tighten - screw down the lower nut in the direction (T).
3. When the chain is at the required tension, screw down the upper nut.
4. Lock the two nuts together to secure in place.
10.17 Adjusting belt alignment
Assuming crop is fed evenly into the bale chamber, generating consistent good profile
bales, the belt(s) should run smoothly and remain in line. All machines are checked
during production, to ensure the belt(s) are properly aligned and tracking correctly.
However, once the machine has been bedded in (50 - 150 bales), and periodically
thereafter, if the belt(s) are touching off the side walls (or each other), then adjustment
may be necessary.
