Function 70 - Report Using Checksum Default - Using checksum
Note:
Not all base stations can handle reporting with checksum.
This function is applicable to ADEMCO high speed reporting only and not CONTACT ID.
Example : While in program mode (Program LED ashing)
Key Sequence Operation
70 - Enter Function No.
0 - Enter Option (0 = no checksum)
On - Store Entry
Installer may now exit program mode by pressing the OFF button or continue programming by enter-
ing a new function number.
Description :
The dialler defaults to use the single
round with checksum.
If a 0 is programmed the dialler will report
in dual round without checksum.
Description :
If enabled the control panel will report
isolated sections at the end of exit time.
Options : (Single digit entry required)
1 Report using checksum
0 Do not use checksum in reporting
Options : (Single digit entry required)
1 Report isolated sections
0 Do not report isolated sections
Function 71 - Report Isolated Sections Default - Report isolates
Example : While in program mode (Program LED ashing)
Key Sequence Operation
71 - Enter Function No.
1 - Enter Option (1 = report isolated sectors)
On - Store Entry
Installer may now exit program mode by pressing the OFF button or continue programming by
entering a new function number.
Function 72 - Report Line Fail Default - Disabled
Options : (Single digit entry required)
0 - Line Fail reporting disabled
1 - Line Fail reporting enabled
Example : While in program mode (Program LED ashing)
Key Sequence Operation
72 - Enter Function No.
1 - Enter Option (1 = Report line fail)
On - Store Entry
Installer may now exit program mode by pressing the OFF button or continue programming by enter-
ing a new function number.
Description :
If enabled the control panel will report
a Line Fail if the voltage across the line
has fallen below 10V for 72 seconds.
When the line has restored for a period
of 12 seconds, a restoral is sent.
Note:
The Fire (now the FAULT) led on the keypad will give a double ash when the line has failed
