Page 19
Options : (Single digit entry required)
0 - RF Module disabled
1 - RF Module enabled
Function 81 - RF Module Enable Default - disabled
Example : While in program mode (Program LED ashing)
Key Sequence Operation
81 - Enter Function No.
1 - Enter Option (1 = ICON RF Module enabled)
On - Store Entry
Installer may now exit program mode by pressing the OFF button or continue programming by en-
tering a new function number.
Description :
This function, if enabled, enables the
ICON RF Module to communicate with the
ICON8V6 via the expansion slot. Reports
Contact-ID code 407 when armed or dis-
armed
Description :
Program the option that will acti-
vate the low current output.
Note :
The line fail timer does not oper-
ate when programmed for GSM
only (Function 67 = 5) therefore
the output will not activate
Options : (Single digit entry required)
0 - Output disabled
1 - Kiss-off (the output will activate for 750msec on
every kiss of received from the monitoring center)
2 - Line Fail (activates the output when the line fails,
follows the line fail timer restoral ie.12sec)
3 - Remote button 3 (Momentary - activates the
output for 750msec when button 3 is pressed from
a fob programmed in the IconRF Module)
4 - Remote button 4 (Toggle - activates the output
when button 4 is pressed, and de-activates the
output when button 4 is pressed a second time)
5 - Report Fail (If after 6 dialling attempts the control
panel is unable to send an event to the monitoring
enter, the output will activate. The output will restore
after the transmission of a successful message.
6 - Chime Output (activates the output for 750msec
when a chime zone programmed in function 84 is
trigggered)
7 - SMS controlled output Sending an output command
to the panel when the GSM module is attached will
toggle the output. The output command format is as
follows [**][XXXX][O][5][T][##] where XXXX is a valid
user code
8 - GSM Fail - GSM not registered (output will occur after
5 minutes of no registration on the network.
.. after which it will report an E352 alarm to MC
Example : While in program mode (Program LED ashing)
Key Sequence Operation
80 - Enter Function No.
4 - Enter Option (Button 4 activates the PGM output)
On - Store Entry
Installer may now exit program mode by pressing the OFF button or continue programming
by entering a new function number.
Function 80 - PGM Programmable Output Default - Kiss-off received
Notes: Keyfobs programmed in the ICONRF Module have the following operation.
Button
1 - Full Arm
2 - Partial Arm
3 - Momentary PGM Output (if programmed in function 80)
4 - Toggle PGM Output (if programmed in function 80)
1 & 2 - Panic (if programmed in function 47)
