Page 23
Notes:
Option 4,5 & 6 has no effect while option 7 is off. When option 7 is on, options 4,5 & 6 need to be
programmed to accept SMS commands from the phone no's in Functions 64,65 & 66. When option
8 is on, SMS command response and SMS reports are sent to the mobile that sent the CMD . When
option 8 is off, only SMS responses are sent to the mobile no. Only the numbers programmed in Func-
tion 64.65.66 will receive the SMS report. The limitation of option 8 when disabled is if a CMD is sent
by SMS to arm/disarm the panel and then armed/disarmed from the keypad there is no event sent by
SMS even though the event has occured from the keypad and not by SMS.
SMS Reporting Notes:
SMS Buffer will allow between 29 - 42 events to be transmitted in one SMS, the number of events in
each SMS depend on the size & number of each individual event message. For eg. Only 29 arm/dis-
arm by keyswitch reports would t in one SMS Vs 42 zone 1 - 8 alarms & restorals. If the no of events
exceeds that of the buffer then the 2nd and 3rd numbers will receive only the events upto the size of
the buffer between 29 - 42 events. In this case, the last event in the SMS may be partially incomplete.
The 1st number is not restricted by the buffer therefore ph 1 will receive all the events generated by
the panel. The network or mobile phone may split the SMS into 1 or more messages depending on the
size of the SMS.
Section LED ON (Flashing) OFF Default
1 SMS to PH 1 ON SMS TO PH 1 OFF ON
2 SMS to PH 2 ON SMS TO PH 2 OFF ON
3 SMS to PH 3 ON SMS TO PH 3 OFF ON
4 SMS CMD from Ph 1 Enabled SMS Cmd from Ph 1 Disabled OFF
5 SMS CMD from Ph 2 Enabled SMS Cmd from Ph 2 Disabled OFF
6 SMS CMD from Ph 3 Enabled SMS Cmd from Ph 3 Disabled OFF
7 SMS CMD Restricted to Ph1,2 & 3 SMS Cmd any mobile number is accepted OFF
8 Send CMD & SMS response Sent response for CMD only ON
Function 88 - SMS Phone number options
