McQuay RPS User Manual

IM-738 Page 91
Figure 93. Keypad Accessible Menu Structure (continued)
Daily Schedule
4 5
Mon= 00:00 - 00:00 Tue= 00:00 - 00:00 Wed= 00:00 - 00:00 Thu= 00:00 - 00:00 Fri= 00:00 - 00:00 Sat= 00:00 - 00:00 Sun= 00:00 - 00:00 Hol= 00:00 - 00:00
One Event Schedule Beg= mmm dd@hh:mm End= mmm dd@hh:mm
Optimal Start Sapce Temp= xxx.x°F Optimal Start= No Auto Update= Yes Htg Rate= 0.4°F/min Htg OAT= 35°F
2nd P Sensor= None DF CapCtrl= DuctPres Remote DF Cap= 25% RF/EF Ctrl= Tracking Rem RF/EF Cap= 25% Eng Units= English
Passwords Timeout= 15min Clear Alarm= No
Operating Hours Fan= xxxxx hr Mech Cool= xxxxx hr Comp 1= xxxxx hr Comp 2= xxxxx hr Comp 3= xxxxx hr Comp 4= xxxxx hr Heating= xxxxx hr Economizer= xxxxx hr Bypass= xxxxx hr
Duct Static P Setup DSP Propbd= 6.0"WC DSP IntTime= 12sec DSP Period= 10sec
Timer Settings Service= 0min Recirculate= 3min Low DAT= 3min Max MWU= 90min Bypass= 120min Start Init= 180sec Post Heat= 0min Min Exh On= 120sec Min Exh Off= 120sec
Time= hh:mm:ss Day= day Date= dd-mmm-yyyy
Fan Tracking DF Max w/oExh= 100%
Fan Balance Fan Balance= Off Set Max w/o Exh= No Set Min w/o Exh= No Set Max w/ Exh= No Set Min w/ Exh= No Rem RF/EF Cap= 25%
Holiday Schedule Hol 1=mmmdd-mmmdd Hol 2=mmmdd-mmmdd Hol 3=mmmdd-mmmdd Hol 4=mmmdd-mmmdd Hol 5=mmmdd-mmmdd Hol 6=mmmdd-mmmdd Hol 7=mmmdd-mmmdd Hol 8=mmmdd-mmmdd Hol 9=mmmdd-mmmdd Hol 10=mmmdd-mmmdd
Hol 11=mmmdd-mmmdd Hol 12=mmmdd-mmmdd Hol 13=mmmdd-mmmdd Hol 14=mmmdd-mmmdd Hol 15=mmmdd-mmmdd Hol 16=mmmdd-mmmdd
Htg Zero OAT= 0°F Clg Rate= 0.4°F/min Clg OAT= 85°F Clg Zero OAT= 100°F
Unit Configuration AHU ID= _____ CompB1 ID= _____ CompB2 ID= _____ GenCB ID= _____ HtgB ID= _____ ERecB ID= _____ KP ID= _____ Calibrate Mode= No Space Sensor= Yes EFT Sensor= No
ERecovery= xxxxx hr
Time/Date
RF@DFMax w/oEx=95% DF Min w/oExh= 20% RF@DFMin w/oEx=15% DF Max w/Exh= 100% RF@DFMax w/Ex=95% DF Min w/Exh= 20% RF@DFMin w/Ex=15%
B
Economizer Setup Clg Propbd= 30°F Clg IntTime= 60sec Clg Period= 30sec
Compressor Setup Lead Circuit= #1 Comp Ctrl= Cross Circ Clg Method= Average Cond Fan1 Spt= 0°F Cond Fan2 Spt= 0°F Cond Fan3 Spt= 0°F Cond Fan4 Spt= 0°F Cond Fan Diff= 10°F Stage Time= 5min
DesignFlow Setup Wait Time= 30sec
Heating Setup Stage Time= 5min F&BP Ctrl= OpenValve F&BP Chgovr= 37°F
Modband= 50% Max Step= 5.0% Deadband= 6.0% LH Flow= xxx.xx% RH Flow= xxx.xx%
Bldg Static P Setup BSP Propbd= 1.0"WC BSP IntTime= 10sec BSP Period= 5sec
Chilled Water Setup Clg Propbd= 30°F Clg IntTime= 60sec Clg Period= 30sec Stage Time= 5min Htg Propbd= 20°F
Htg IntTime= 120sec Htg Period= 60sec
A
Sub Menus (Continued)
Zone Temp Setup Spt Source = Keypad Clg Propbd = 8.0°F Htg Propbd = 12.0°F Clg IntTime = 700sec Htg IntTime = 500sec Period= 60sec
Parameters for Discharge Air Temperature Control Parameters for Space Temperature Control Parameters Common to Both Control Methods
Control Parameter Legend
