Mec 2033ES - Optional Swing Gate Parts and Installation

ITEM PART NO. QTY DESCRIPTION
"2033ES - 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page B-11
SWING GATE (OPTION)
1 15040 1 SWING GATE WELDMENT
2 40003 1 PIN, LATCH
3 40006 1 ROD, LATCH LEVER
4 7055 1 SPRING, LATCH
5 HDW8277 1 SCREW, 3/8" - 16, 1 3/4" LG
6 HDW6281 1 NUT, 3/8" - 16
7 25615 1 BRKT STRIKER SWING GATE
8 15046 1 SWING GATE MOUNT WELD UPPER
9 15043 1 SWING GATE MOUNT WELD LOWER
10 8187 2 BEARING, NYLINER, FLANGED
11 8300 1 SPRING, TORSION, 1" OD, 4" LG
12 HDW7455 1 PIN, SLOTTED SPRING, 3/16" DIA X 3/4" LG
13 13272 1 BLOCK, PIVOT
14 HDW7119 4 HEX CAP SCREW 5/16"-18 X 2.25"
15 HDW8294 8 FLAT WASHER 0.328 ID
16 HDW8304 6 LOCNUT 5/16"-18
17 HDW5724 2 HEX CAP SCREW 5/16"-18 X 3/4"
18 HDW5217 2 FLAT WASHER 11/32" ID
