ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page D-7
MAIN MANIFOLD ASSEMBLY, EARLY MODELS
2033ES - SERIAL #TO # 8804099
2633ES - SERIAL # 11100000 TO # 11100599
21 HDW7389 8 ADAPTER, MALE 3/8", MALE 3/8" O-RING
23 HDW90364 1 FITTING, 45° 6MB-6MJ
25 HDW90299 1 FITTING, 90° ELBW, MALE 3/8", FML 3/8", MALE 3/8"
26 9980 1 FITTING, 90° ELBW, MALE 3/8" O-RING, FML 1/4" NPT
27 HDW90301 1 UNION, MALE 1/4" NPT, MALE 1/4" NPT,3" LG
28 HDW7971 1 DISCONNECT, MALE 1/4"
29 HDW90287 2 SCREW, 1/4" - 20, 4.5" LG
30 HDW5277 2 WASHER, LOCK
31 HDW5217 2 WASHER, FLAT
32 HDW90327 1 FITTING, 90° ELBW, MALE 1/4", MALE 3/8" O-RING
33 2974 1 PLUG, METERING
34 HDW90285 1 FITTING, MALE 3/8" TEE
35 HDW90329 1 FITTING, 90° ELBW, MALE 1/4", MALE 3/8" O-RING
36 HDW9200 1 FITTING, MALE PLUG 1/4" NPT
37 91014 1 FLOW DIVIDER
38 9971 3 RELIEF VALVE TAMPER PROOF CAP
25575 - HOSE KIT, SEE HYDRAULIC HOSES
