"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page VII
Component Service Section Parts Section Component Service Section Parts Section
PRIMARY MACHINE COMPONENTS
Use this chart to find information relating to a specific component.
Pump Compartment
Hydraulic Pump & Motor intro | 1 | 4 | 5 E
Hydraulic Reservoir intro | 1 D
Battery Charger 2 | 4 | 5 D
Base Assembly
Drive Motors intro | 1 | 3 | 4 | 5 E
Brakes intro | 1 | 3 | 4 | 5 E
Steering Components 1 | 3 | 4 | 5 E
Wheels & Tires 3E
Emergency Lowering1 E
Hoses & Cables 1 | 3 A | B | D
Pothole Components 3E
Pothole Switch 2 | 4 | 5 E
Limit Switch 2 | 4 | 5 E
Lubrication Points introC
Hydraulic Filter intro | 1 D
Lift Assembly
Scissor Assembly 3 C
Maintenance Lock introC
Lift Cylinder 1 | 3 | 4 | 5 C
Platform Assembly
Upper Controls 2 | 4 | 5 A
Deck and Rails 3B
Chain ClosureB
Optional Gate B
Deck Extension B
Control Terminal Strip 2 | 5 A | B
Horn (optional) 2 | 4 | 5 A | B
Power to PlatformB
Lower Control Box
Lower Controls 2 | 4 | 5 A
Power to Platform2A
Tilt Sensor 2 | 4 | 5 A
Diode Board 2 | 4 | 5 A
Motor Controller (PWM) 2 | 4 | 5 A
Battery Disconnect Switch 2 A
Motion Alarm2 | 5E
Battery Compartment
Battery Pack 2 | 4 E
Hydraulic Manifold 1 | 4 | 5 D
Brake Release Hand Pump 4 | 5 D
