October 2008 "2033ES / 2633ES" Service & Parts Manual - ANSI Specifications
Page 1-6
PARKING BRAKE AND TOWING CIRCUIT
Note: Refer to
Parts Section E
for hose routing.
Machine can be winched or moved short distances in case of power failure at speeds not to
exceed 5 m.p.h. (8.05 km/h).
PRIOR TO MANUALLY RELEASING BRAKES, INSURE WHEELS ARE
CHOCKED TO PREVENT MACHINE FROM MOVING.
Release Brakes Before Towing:
♦ Open the tow valve by turning counter-clockwise.
♦ Push in the manual Brake Release valve located on the main manifold.
♦ Using the hand pump on the manifold, pump valve until pressure is built.
♦ Machine is now ready for towing.
AFTER RELEASING THE BRAKES, THERE IS NOTHING TO STOP
THE MACHINE’S TRAVEL. MACHINE WILL ROLL FREELY ON
SLOPES. BE ON GUARD AGAINST RUNAWAY.
To Reset Brakes:
♦ Close the tow valve by turning clockwise.
♦ Brakes will reset when drive function is activated or reset by pulling on manual brake re-
lease valve.
