October 2008 "2033ES / 2633ES" Service & Parts Manual - ANSI Specifications
Page 5-2
HYDRAULIC SCHEMATICS
2033ES - Serial # 8804000 - 8804099
2633ES - Serial # 11100000 - 11100599
ITEM DESCRIPTION Location
CBV1 Counterbalance Valve Main Manifold (MA-1)
CV1 Check Valve Main Manifold (MA-1)
CYL1 Steering Cylinder Machine Base, Front
CYL2 Lift Cylinder, 2047, 2647 Scissor Assembly
FD1 Flow Divider Main Manifold (MA-1)
HP1 Hand Pump, Brakes Brake Release Manifold (MA-2)
MA-1 Main Manifold Assembly Battery Compartment
MA-2 Brake Release Manifold Battery Compartment
MA-3 Manifold Assembly Lift Cylinder
MV1 Manifold Valve Main Manifold (MA-1)
NV1 Needle Valve Main Manifold (MA-1)
ORF1 Orifice Plug, Wheel Motors Main Manifold (MA-1)
ORF3 Orifice, Down Valve Lift Cylinder Manifold (MA-3)
P1 Pump Pump Compartment
PCF1 Steering Relief Flow Control Main Manifold (MA-1)
RV1 Relief Valve, Lift Relief Main Manifold (MA-1)
RV2 Relief Valve, Main Relief Main Manifold (MA-1)
RV3 Relief Valve, Steering Main Manifold (MA-1
SV1 Spool Valve, Steering Main Manifold (MA-1)
SV2 Spool Valve, Lift Main Manifold (MA-1)
SV3 Spool Valve, Drive Main Manifold (MA-1)
SV4 Spool Valve, Decel Main Manifold (MA-1)
SV5 Spool Valve, Torque Main Manifold (MA-1)
SV6 Spool Valve, Torque Main Manifold (MA-1)
SV7 Spool Valve, Brakes Main Manifold (MA-1)
SV8 Poppet Valve, Down Main Manifold (MA-1)
SV9 Spool Valve, Down Lift Cylinder Manifold (MA-3)
TP1 Test Port Main Manifold (MA-1)
WB1 Wheel Brake Drive Wheel
WB2 Wheel Brake Drive Wheel
WM1 Wheel Motor, Right Side Machine Base
WM2 Wheel Motor, Left Side Machine Base
