ITEM PART NO. QTY DESCRIPTION
"2033ES - 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page B-17
TERMINAL BLOCK
1 HDW5363 2 SCREW, 6-32, 1" LG
2 HDW6455 4 SCREW, 1/4" - 20, 1/2" LG
3 5882 2 CABLE CLAMP
4 HDW5364 2 NUT, 6-32
5 5991 1 TERMINAL BLOCK
6 7817 1 STRIP, BACKING, 15 POSITION
7 REF 1 WIRE HARNESS, UPPER CONTROLS
8 25526 1 TERMINAL STRIP COVER
O
PERATOR HORN (ANSI OPTION)
10 9716 1 HORN, 12-48 VOLT ELECTRONIC
HDW5723 2 SCREW, 1/4" - 20, 3/4" LG
HDW5276 2 NUT, 1/4" - 20
HDW5217 2 WASHER, FLAT
A
IRLINE TO PLATFORM (OPTION)
NOT SHOWN
5351 1 CABLE TIE
8543 * HOSE, 1/4" AIRLINE
* 2033ES = 34 FT.
* 2633ES = 41 FT. 6 IN.
8559 2 CLAMP, HOSE
HDW5052 2 FITTING, 1/4" MALE, MALE HOSE BARB
