Mec 2033ES - Pothole Assembly Parts Breakdown

ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page E-23
POTHOLE ASSEMBLY
1 HDW8279 4 BOLT, CAP HEX HD, 3/8" -16, 2.50" LG, GRADE 5, ZI/CL
2 13548 2 ROD, ACTUATOR SPRING TUBE
3 HDW13556 4 WASHER, FLAT, PLASTIC, ID .391", OD 1.5", .125" THK
4 8602 4 SPACER, STEPPED, PVC
5 13461 2 PLATE, SLIDE POTHOLE PROT.
6 HDW8312 4 NUT, HEX, 5/16"-18, CLASS 5, ZI/CL
7 HDW8310 4 BOLT, CAP, HEX HD, 1/2"-13, 3.00" LG, GRADE 5, ZI/CL
8 8226 2 SPRING, TENSION, .75" X .564" X 5", K9.3+3.5
9 HDW7018 2 BOLT, CAP, HEX HD, 1/2"-13, 3.00" LG, GRADE 5, ZI/CL
10 HDW13195 2 WASHER, FLAT, ID .515", OD 1.512", .098" THK, ZI/YEL
11 HDW90770 1 PIN, CLEVIS, 1/2" X 1.375" LG, ZI/CL
12 7200 2 BEARING, 1/2" ID X 1/2" LG, NYLINER
13 HDW8179 2 PIN, CLEVIS, 1/2" X 2.62" LG, ZI/YEL
14 HDW8273 8 BOLT, CAP, HEX HD, 1/4"-20, 1.00" LG, GRADE 5, ZI/CL
15 7015 4 BEARING, FLANGED, NYLINER
17 HDW5920 4 PIN, COTTER, HAMMERLOCK, 1/8" X 1.00", ZI/CL
18 13842 1 BRACKET, POTHOLE SWITCH ACTIVATOR, RH
19 13839 1 BRACKET, POTHOLE SWITCH ACTIVATOR, LH
20 HDW8457 2 NUT, LOC, HEX HD, 1/2"-13, CLASS B, ZI/CL
21 5736 2 RING, RETAINING, EXTERNAL, 1/2" SHAFT
22 HDW7031 2 WASHER, FLAT, ID .5", OD .875", .074 THK, ZI/YEL
23 4542 2 ROLLER
24 13770 2 LINK, POTHOLE
25 13766 1 BAR, POTHOLE, LH
26 13767 1 BAR, POTHOLE, RH
27 8181 2 BEARING, 1/2" X 5/16", NYLINER
28 13178 4 WELDMENT, PIVOT PIN
29 15039 2 WELDMENT, LEVER
30 7638 1 STRAP, GROUNDING
31 8225 2 BEARING, NYLINER, 16L16
32 13194 2 TUBE, PIVOT-POTHOLE LEVER
33 HDW8494 2 BOLT, TAP, HEX HD, 3/8"-16, 2.00" LG, GRADE 5, ZI/CL
34 HDW5355 2 WASHER, FLAT, ID .438", OD 1.00", .078" THK, ZI/CL
35 13464 2 WELDMENT, ACTUATOR SPRING TUBE
36 13478 2 SPRING, COMP, 1.68" X 1.251" X 7.00"
