Mec 2033ES - Section C: Scissors

"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page C-1
SECTION C:
SCISSORS
SCISSOR ASSEMBLY - 2033ES, SERIAL # UP TO 8804199 ............................................................. C-3
S
CISSOR ASSEMBLY - 2033ES, SERIAL # 8804200 - UP ................................................................ C-5
S
CISSOR ASSEMBLY - 2633ES, SERIAL # UP TO 11100999 ........................................................... C-7
S
CISSOR ASSEMBLY - 2633ES, SERIAL # 11101000 -UP ............................................................... C-9
S
CISSOR ASSEMBLY MOUNT ....................................................................................................... C-11
L
IFT CYLINDER MOUNT .............................................................................................................. C-13
L
IFT CYLINDER, 90637 ............................................................................................................. C-15
L
IFT CYLINDER, 90802 WITHOUT EMERGENCY LOWERING CABLE .................................................... C-17
L
IFT CYLINDER AND EMERGENCY LOWERING CABLE W/ BELL CRANK ................................................. C-19
L
IFT CYLINDER AND EMERGENCY LOWERING CABLE, W/O BELL CRANK .............................................. C-21
