ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page C-7
SCISSOR ASSEMBLY - 2633ES, SERIAL # UP TO 11100999
1 13968 1 BEAM 5 X 5 X .250 W/PINS
6669 2 BEARING, 2.0 X 2.0 LG
2 15051 1 BEAM 5 X 5 X .188 TS W/PINS
3 15074 1 BEAM 5 X 5 X .188 TF W/BEARINGS
6669 4 BEARING, 2.0 X 2.0 LG
4 13964 1 MAINTENANCE LOCK WELDMENT
5 13054 2 CYLINDER MOUNT WELDMENT
6 13931 1 SUPPORT BEAM WELDMENT
7 13966 1 BEAM 5 X 5 X .250 W/ BEARINGS
6669 6 BEARING, 2.0 X 2.0 LG
8 15077 1 BEAM 5 X 5 X .250 W/PINS
9 15052 1 BEAM 5 X 5 X .250 W/PINS
10 15076 1 BEAM 5 X 5 X .250 W/BEARINGS
6669 6 BEARING, 2.0 X 2.0 LG
11 15075 1 BEAM 5 X 5 X .250 W/BEARINGS
6669 6 BEARING, 2.0 X 2.0 LG
12 HDW13175 16 WASHER, NYLON, 2.06 ID, 2.62 OD, .030 THK
13 25429 12 SPACER, RUBBER
14 6701 12 RETAINING RING, 2.0 DIA.
— 7041 5 HOSE CLAMP (NOT SHOWN)
— HDW5723 5 SCREW, 1/4" - 20 X 3/4" LG SELF TAPPING (NOT SHOWN)
— 9146 1 HOSE CLAMP (NOT SHOWN)
— 90765 14.5' CABLE WRAP (NOT SHOWN)
