ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page C-11
SCISSOR ASSEMBLY MOUNT
1 13778 2 BLOCK, SLIDE PLATFORM
2 13777 2 BLOCK, FIXED PLATFORM
3 HDW8486 4 SCREW, 5/16-18, 1.87 LG, GR 8
4 HDW5217 4 WASHER, .343 ID X .688 OD X .063 THK
5 HDW8294 4 WASHER, .328 ID X 1.000 OD X .100 THK
6 HDW8304 4 NUT, 5/16-18, GR 5
7 13782 1 SLIDE SHOE, MACHINED
8 8731 2 WIPER SLIDE
9 13785 2 PLATE, SLIDE RETAINER
10 HDW8152 8 SCREW, 1/4-20, 3/4 LG GR 5
11 6669 2 BEARING, 2.0 X 2.0 LG
12 15134 4 BEARING, LINEAR SLIDE
13 HDW13175 16 WASHER, NYLON, 2.06 ID, 2.62 OD, .030 THK
14 13087 1 PIN, 2.000 DIA. X 11.026 LG
15 6701 12 RETAINING RING, 2.0 DIA.
16 13101 2 PIN WELDMENT STATIONARY MOUNT
17 HDW8283 6 SCREW, 1/2-13, 1.5 LG, GR 8
18 HDW8457 6 NUT, LOCK, 1/2-13
