ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page C-13
LIFT CYLINDER MOUNT
1 REF 2 CYLINDER MOUNT WELDMENT
REFER TO SCISSOR ASSEMBLY
2 25219 2 PLATE RETAINER, CYL MOUNT 3.75 X 1.25 X 0.179
3 HDW6455 4 SCREW, 1/4-20, 1/2 LG, GR 5
4 13339 4 WASHER, NYLON, 1.385 ID X 2.255 OD X .030 THK
5 25142 2 PIN, 1.373 X 5.382 CYL MOUNT
6 6984 4 BEARING, 1.375 X 1.625 LG
7 6875 2 RETAINING RING, 1.375 DIA.
8 REF 1 LIFT CYLINDER (SEE FOLLOWING PAGES)
