ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page C-15
LIFT CYLINDER, 90637
2033ES - SERIAL # 8804000 - 8804007
2633ES - SERIAL # 11100000 TO # 11100315
1 90637 1 CYLINDER, LIFT
2 REF 1 HOSE ASSEMBLY, LIFT CYLINDER (SEE SECTION D)
3 HDW7438 1 FITTING, PIPE, ADAPTOR
4 HDW8592 4 SCREW, CAP, SOCKET HD, 1/4"-20 X 1.50, GRADE 8
5 13551 1 MANIFOLD, LIFT CYLINDER-STANDARD
6 8595 1 VALVE, 2 WAY, N.C. W/MANUAL LOCK
7 8914 1 COIL, 24 VOLT, DOUBLE SPADE W/DIODE
8 HDW8663 2 SCREW, CAP, HEX HD, 5/16"-18 X .50, GRADE 2
9 13728 1 BRACKET, CYLINDER VALVE GUARD WELDMENT
10 90638 1 KIT, SEAL-LIFT CYLINDER (SERVICE)
11 6426 1 O-RING, MANIFOLD BLOCK
12 REF 13' HOSE, RETURN LINE (SEE SECTION D)
13 6984 4 BEARING, DU, 1 3/8" ID X 1 5/8" LG
14 7788 1 CLAMP, HOSE
15 90439 1 ORIFICE
16 HDW90863 1 FITTING, 90° ELBOW, MALE 1/4" O-RING, FML 1/4" O-RING
17 90845 1 PRESSURE SENSOR, 3000 PSI
— REF 1 HARNESS, WIRE DOWN, VALVE (SEE PARTS SECTION A)
