"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page D-9
MAIN MANIFOLD ASSEMBLY, LATE MODELS
2033ES - SERIAL # 8804100 UP
2633ES - SERIAL # 11100600 UP
1 91002 5 COIL
2 91001 3 COIL
3 91003 1 VALVE, SPOOL 4 WAY 2 POSITION (LIFT)
4 91004 1 VALVE, SPOOL 4 WAY 3 POSITION (STEERING)
5 91005 1 VALVE, SPOOL 4 WAY 2 POSITION (TORQUE)
6 91008 1 VALVE, SPOOL 4 WAY 3 POSITION (DRIVE)
7 91007 1 VALVE, SPOOL 2 WAY N.O. (TORQUE)
8 91006 1 VALVE, SPOOL 4 WAY 2 POSITION (DRIVE DUMP/DECEL)
9 9998 1 ORIFICE 0.040
10 91016 1 VALVE, NEEDLE (TOW/FREEWHEEL)
11 91015 1 PUMP, MANUAL (BRAKE)
12 91012 1 VALVE, MANUAL (BRAKE RELEASE)
13 91010 1 VALVE, RELIEF (MAIN)
14 91009 1 VALVE, RELIEF (LIFT)
15 91011 1 VALVE, RELIEF (STEER/PRIORITY FLOW CONTROL)
16 91013 1 VALVE, RELIEF (COUNTERBALANCE WITH PISTON)
17 91014 1 VALVE, CHECK (FLOW DIVIDER)
21 HDW91080 1 FITTING, 90° ELBOW, ¼" MALE O-RING × ¼" MALE NPT
22 HDW7601 1 FITTING, 90° ELBOW, 3/8" MALE O-RING × 3/8" MALE JIC
23 HDW8881 3 FITTING, ¼" MALE O-RING × ¼" MALE JIC
24 HDW7438 6 FITTING, 3/8" MALE O-RING × 3/8" MALE JIC
26 HDW7971 1 DISCONNECT, MALE 1/4"
31-38 REF SEE HYDRAULIC HOSES
