Mec 2033ES - Hydraulic Pump Assembly Parts

ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page E-21
HYDRAULIC PUMP ASSEMBLY
2033ES - SERIAL # TO # 8804107
2633ES - SERIAL # TO # 11100666
2 8544 1 MOTOR, 24 VDC, 2 HP
3 8546 1 PUMP
14 6314 1 COUPLER
2033ES - SERIAL # 8804108 - UP
2633ES - SERIAL # 11100667 - UP
1 90970 1 POWER UNIT ASSEMBLY
2 90997 1 MOTOR, 24 VDC, 2 HP
91226 1 BRUSHES
3 90998 1 PUMP
14 90999 1 COUPLER
4 HDW8081 1 FITTING, 90° ELBW, MALE 1/2" O-RING, MALE 3/8" SIZE: 37
5 HDW90967 1 FITTING, 90° ELBW, MALE 3/8" O-RING, MALE 1/2" SIZE: 50
6 REF 1 BATTERY CABLE, RED (SEE HARNESSES, PARTS SEC 1)
- 7172 1 BOOT TERMINAL INSULATOR RED (NOT SHOWN)
7 REF 1 BATTERY CABLE, BLACK, (SEE HARNESSES, PARTS SEC 1)
- 7172 1 BOOT TERMINAL INSULATOR BLACK (NOT SHOWN)
9 HDW5005 4 NUT, 5/16" - 18
10 HDW5204 4 SCREW, 5/16" - 18, 1" LG
12 HDW5724 4 SCREW, 5/16"–18, 3/4" LG
13 HDW5006 4 LOCKWASHER, 5/16"
SEE HYDRAULIC HOSES (SECTION 4)
