—Specifications—
6092RT
Working Height* Outriggers Deployed 66 ft* 20 m*
Outriggers Not Deployed 36 ft* 11 m*
Platform Height Outriggers Deployed 60 ft 18 m
Outriggers Not Deployed 30 ft 9 m
Stowed Height Rails Up 128 in 3.25 m
Rails Folded Down 97 in 2.46 m
Maximum Occupants 4
Lift Capacity 1200 lbs 545 kg
Length (inside rails) 202 in 5.13 m
Platform Width (inside rails) 75 in 1.91 m
Guardrail Height 44.75 in 1.14 m
Toeboard Height 7 in 18 cm
Overall Length 209 in 5.31 m
Overall Width 92 in 2.34 m
Wheel Base 114 in 2.9 m
Wheel Track 80 in 2.03 m
Turning Radius Inside 7 ft 0 in 2.13 m
Outside 17 ft 6 in 5.33 m
Ground Clearance 13 in 43 cm
Machine Weight** (Approximate, unloaded) 21,780 lb** 9880 kg
Drive System (Proportional)
Drive Speed - Platform Elevated 0-.25 mph 0-.4 km/h
Drive Speed - Platform Lowered 0-4.4 mph 0-7.0 km/h
Lift/Lower Speeds (Approximate) 72 sec/102 sec
Gradeability 40%/22°
Ground Pressure/Wheel (Maximum) 80.4 psi 5.65 kg/cm
Wheel Load 6900 lb 3130 kg
Wind Speed (Maximum) 28 mph 45 km/h (12.5 m/s)
Noise Level (Maximum) 86 dB
Tire Size - Standard 315/55 D20 foam-filled
Wheel Lug Nut Torque 120 ft/lb 162.7 Nm
Hydraulic Pressure Drive System 4500 psi 310 bar
Lift System 2800 psi 193 bar
Steering System 2800 psi 193 bar
Hydraulic Fluid Capacity 40 gallon 151 liters
Power Source Kubota V-2403T diesel
Ambient Operating Range -30° C minimum; 50° C maximum
Fuel Capacity 25 gallon 95 liter
Brakes 4 Wheel Multi-Disc
Sound Pressure At Workstation 80 dB(A)
Sound Power Level 86 dB @ 1m
Total vibration value to which the hand/arm system is subjected does not exceed 2.5 m/sec
2
.
Highest root mean square value of weighted acceleration to which the whole body is
subjected does not exceed 0.5 m/sec
2
.
Meets requirements of EN280:2013 and Australian Standard AS/NZS1418.10:2011.
*Working Height adds 2m to platform height. **Weight may increase with certain options or
country standards.
