Mecmesin Multitest 0.5d - Page 22

Multitest 0.5d, 1d & 2.5d
Service and Repair Manual
Number 022-005
Issue Number: 08
Page 22 of 58
73. Remove front panel components
as described in the following
instructions.
74. Re-assemble with replacement
parts as necessary.
Refitting of the Front Panel
is the reverse of the above procedure
Note: When refitting the front panel, ensure that the self-adhesive EMC gasket
material is not disturbed. Replace damaged sections or the entire gasket if
necessary.
