Mecmesin Multitest 0.5d - Spare Parts List

Multitest 0.5d, 1d & 2.5d
Service and Repair Manual
Number 022-005
Issue Number: 08
Page 56 of 58
35. Spare Parts List
PCB’s supplied will not be accepted back for credit due to obvious handling and
storage problems.
Part No.
Req’d
Description
900-393
1
PARVALUX 0.5 TO 2.5d SPARES KIT
900-394
1
DUNKER 0.5 TO 2.5d SPARES KIT
300-163-V01
1
MT-d MOTOR CONTROL ASSY PARVALUX
300-163-V02
1
MT MOTOR CONTROL ASSY DUNKER
300-164-V01
1
MT-d FRONT PANEL PCB ASSY – To ensure the correct
‘readability’ a 301-032-V01 is also required.
301-032-V01
1
MT-d LCD MODULE ASSY – To ensure the correct
‘readability’ a 300-164-V01 is also required.
428-186
1
MT-d LCD MEMBRANE KEYPAD only supplied affixed to 404-193
MT-d FRONT PANEL c/w 305-026 EMERGENCY STOP BUTTON
325-015
1
FUSE pcb 6.3A CERAMIC ANTISURGE
325-008
2
FUSE mains inlet 2A 20mm x 5mm T (Time lag).
329-239
1
DELTA MAINS INLET FILTER 6A
432-448
1
LIMITSWITCH COMPLETE ASSEMBLY Mk1 MT 1-d, Mk2
MT 2.5-d
432-449
1
LIMITSWITCH COMPLETE ASSEMBLY Mk1 MT 2.5-d, Mk2
MT 1-d
406-422
1
MULTITEST Mk1 MT 1-d, Mk2 MT 2.5-d LIMIT SWITCH ROD
406-403
1
MULTITEST Mk1 MT 2.5-d LIMIT SWITCH ROD
406-569
1
MULTITEST Mk2 MT 1-d LIMIT SWITCH ROD
406-570
1
MULTITEST Mk2 MT 0.5-d LIMIT SWITCH ROD
300-148-V01
1
LIMIT SWITCH PCB - ONLY
307-044
2
OPTO SWITCH OPB625 (Component of above).
352-198
1
LOOM TRANSFORMER ASSY
352-084
1
LOOM EARTH FILTER
352-086
1
LOOM EARTH REAR PANEL
352-131
1
LOOM EARTH LIMIT SWITCH
352-188
1
LOOM EMERGENCY STOP (inc E Stop contact block)
352-189
1
LOOM SPI
352-190
1
LOOM COMMUNICATIONS
352-192
1
LOOM FRONT PANEL RS232 (connects between the Front
Panel PCB and the Motor Control PCB)
352-193
1
LOOM REAR PANEL RS232 (connects the Motor Control
PCB to the PC socket labelled RS232 on the back of the test
stand.)
305-026
1
EMERGENCY STOP BUTTON only (see 352-188)
331-076
1
MECHANICAL ROTARY ENCODER (SPEED POT).
413-052
1
BLACK ALUMINIUM KNOB (SPEED POT).
413-013 /420-020
2
M4 KNOBLET (The screw is to be supplied with this).
