Multitest 0.5d, 1d & 2.5d
Service and Repair Manual
Number 022-005
Issue Number: 08
Page 49 of 58
The RS232 loom 352-192 in the photos, also referred to as RS232 Front, connects between the
Front Panel PCB to the Motor PCB.
This is not to be confused with RS232 Rear – 352-193 is the loom with the PC connection to the
back panel.
