The Aux. Out jack
The AUX. OUT jack delivers the output of the keyboard for connection to an external amplifier.
Using an audio cord, plug into AUX. OUT jack located on the rear panel. Then plug the other
end of the cord into LINE IN or AUX. IN of the amplifier.
Stereo
System
DC 12VPHONES
AUX
OUT
DAMPERMIDI OUTMIDI IN VOLUME
The volume jack
An optional volume control can be plugged into the VOLUME jack for adjusting the volume of sound.
DC 12VPHONES
AUX
OUT
DAMPERMIDI OUTMIDI IN VOLUME
The MIDI IN/OUT jacks
The MIDI IN connector receives MIDI data from an external MIDI device. The MIDI OUT connector
transmit MIDI data generated by the electronic keyboard to an external MIDI device.
MIDI OUTMIDI IN
7
