Router calibration
Router calibration
The calibration feature is used when the machine moves in one axis incorrectly, i.e. too much or
to little, and if the error is proportional along the entire length of the axis. You can set the calibration
adjustment for each axis separately.
In order to calibrate the machine in this way, create a text file named kalibracja.txt The file
should have three lines, and each line should have the calibration value for the given axis: X, Y
and Z np.:
Kalibracja.txt
1.003 increases movement by 3mm in X axis
0.999 decreases movement by 2mm in Y axis
1.000 no calibration in X axis
For axis not requiring calibration, set the value to 1.0. This calibration files should be placed in
the main MegaCut folder where the frez_mdi.exe is located.
The calibration must be within the range <0.99; 1.01> so it can correct errors of +/-10mm.
The calibration value can be calculated in the following way:
calibration value =
