Megger Baker ADX User Guide
38
Key Concepts
Comparing AWA and ADX Data Models
AWA ADX
Traditional fixed hierarchy Flexible dynamic mapping
Data collection limits Unlimited data collection options (via
attributes)
Motor ID can be motor-focused or
machine-focused
Asset and Installation clearly separated
Fig 38: Comparing AWA and ADX data models.
Build the Strategy that Realizes Your Vision
A few examples are presented next, but your actual applications are limited only by your imagination.
You envision what data will reveal how your assets and installations perform. The ADX helps you build a strong
foundation around these key elements, and attributes provide the power and flexibility to realize your vision.
