Manual Tests
Main Menu—Manual Tests
Clicking on the MANUAL TESTS icon reveals a screen containing icons that provide access to manual RLC, HiPot, Surge,
and Coil tests.
NOTE: The icons shown in this screen can vary depending on roles and permissions assigned to the user.
You can also select REPORTS to view report results or to generate new reports for completed tests.
Press the LOGOUT icon to sign out of your user profile and return to the Login screen when you have completed your
tasks.
Fig 78: Manual Tests Main menu.
Refer to chapter “3 — Preparing the Megger Baker ADX for Testing” to ensure that the ADX Test Leads are properly
connected to the asset being tested.
www.megger.com
Megger Baker ADX User Guide
83
Manual Tests
