26 TORKEL 900-SERIES ZP-CS01E CS033663DE
5 MAKING A TEST
3] Disconnect the cables in reverse order as
described in section "Connecting the current
cables to the battery" on page 20
WARNING
Do not connect a discharged battery to a
battery that has not been discharged. The
batteries must be charged to the same
potential (voltage) before they are con-
nected together.
5.7 Viewing results and
reporting
Viewing the results
1] Select the "RESULT" tab to view the test
results
2] In the RESULT and BATTERY tabs you can add
information by pressing the "Edit" button.
Float voltage The voltage value prior the charger is
removed.
Open voltage The value prior start of discharge
test.
Start voltage The value given after the first initial
decrease of the battery bank at a
start of a discharge test.
End voltage The value at the end of discharge test
REPORT
The saved test can be stored on an USB memory stick
and transferred to a PC. The included PC software
TORKEL Viewer can be used to edit and print out
reports, see paragraph "4.2 TORKEL Viewer" on page
19.
