SDM-9XXX Series Hardware Installation Guide
5-4 Memotec Inc.
5.3 Connecting the User Equipment
To connect the user equipment to the serial port:
1. Locate the HD-26 custom cable that is appropriate for:
- The device you are attaching: DTE or DCE
- The interface you want to use: V.35/V.11, TIA-232 (V.24), X.21, X.21 EU,
TIA-449 (V.36) or TIA-530.
2. Connect the male end of the HD-26 cable to a serial port on the SDM-9220/9230.
3. Connect the other end of the cable to the user device (CSU/DSU, modem, router,
front end processor, etc.).
CAUTION:: Do not connect a data port (WAN/user) to a host, PU,
or Frame Relay device until you have configured the port protocol
via the software. Refer to the NetPerformer Reference Guides for
details.
5.3.1 Activating the User Equipment Connection
CAUTION:: Configure the E&M interface type before you connect
the cables to ports on the E&M interface card. Otherwise, the
interface card could be damaged. FXO, FXS and digital voice
channels can be configured before or after cable connection.
To activate the user equipment connection:
1. Configure all parameters and options for the connection. Refer to the NetPerformer
Reference Guides, which is included on the NetPerformer Documentation CD.
2. Activate a data connection by bringing up the connected user equipment.
3. Activate a voice connection by dialing a speed dial number to place a call.
4. Check the status of the NetPerformer, its connections and all active channels, ports,
PVCs and SVCs by executing the statistics commands (refer to the NetPerformer
Reference Guides for details).
