3.14 Connecting the LAN Hub
You must provide a standard straight through Ethernet 802.3 LAN cable (10/100BaseT,
RJ-45M to RJ-45M) for connection to each LAN port. LAN cables are not provided with
the product package.
To connect the SDM-9120/9220/9230 unit to a LAN hub:
1. Connect one end of the LAN cable to one of the SDM-9120/9220/9230 Ethernet LAN
ports, labelled ETHERNET on the rear panel. Refer to Figure 4-2 in “Rear View of
the SDM-9230 UAC” on page 4-3.
2. Connect the other end of the LAN cable to one of the 10/100BaseT ports on your local
LAN hub.
3. The link is up when the
LNK LED is on. The LED color indicates the speed of the
LAN connection:
• Amber: 100 Mbps
• Green: 10 Mbps
