4.1 SDM-9120 Base Unit
Figure 4-1: Rear View of the SDM-9120
Item Details
Base unit chassis, with two slots for interface
cards
“Base Unit Chassis” on page 4-5
Two Ethernet ports (require customer-supplied
LAN cables)
“Ethernet Ports” on page 4-7
One serial port (requires custom serial cable) “Serial Port” on page 5-2
One console port, with console cable “Console Port” on page 4-9
One UAC power supply, with removable power
cable.
“Power Supply” on page 4-10
One rackmount kit “Rackmount Kit” on page 4-11
Table 4-1: Basic features of the SDM-9120 unit
Interface card slots
LAN status LEDs
Console portSerial portEthernet ports (2)
System status LEDs
Power supply
Ground lug
