Quick Reference Engineers Menus
Engineers Menu 1
key Options Page
1
Program Keypad Outputs
1 = Kepad Output 1
2 = Kepad Output 2
3 = Kepad Output 3
4 = Kepad Output 4
22
2
Program Digicom Outputs
1 = Channel 1
2 = Channel 2
3 = Channel 3
4 = Channel 4
5 = Channel 5
22
3
Program Digicom Channels
1 = Channel 1 5 = Channel 5
2 = Channel 2 6 = Channel 6
3 = Channel 3 7 = Channel 7
4 = Channel 4 8 = Channel 8
22
4
Program Circuits & Attributes
Circuit Types Circuit Attributes
0 = Not Used 1 = Access
1 = Night 2 = D Knock
2 = 24 Hour 3 = Test
3 = PA Silent 4 = Omit
4 = PA Audible 5 = Reset
5 = Fire 6 = Monitored
6 = Auxiliary 7 = Entry
7 = Final Exit 8 = Chime
8 = Exit Term.
9 = Keypoint
25
5
System Timers
00 = Abort Delay 12 = Monitor Dur.
01 = No Rearms 13 = Pset Bell Dly
02 = Settle Time 14 = Courtesy Dur.
03 = Pset Com Dly 15 = No Rem. Resets
04 = Exit time 16 = Modem Rings
05 = Entry Time 17 = PID Alarms
06 = Bell Dur. 18 = AC Off Delay
07 = Bell Dly 19 = Test Call
08 = 2nd Act Time 20 = 2nd Alarm Time
09 = Test Time 21 = Line Fault Dly
10 = 2nd Entry 22 = Service Time
11 = Part Set Entry 23 = Test Call At
27
6
Setting Modes
0 = Full Set 1 = Final Exit
A = Part Set A 2 = Exit Terminator
B = Part Set B 3 = Timed Exit
C = Part Set C 4 = Instant
5 = Deferred
29
7
System Print-Out
29
8
Remote Reset Algorithm
Enter Algorithm number 004 - 199.
30
key Options Page
9
System Configuration
No. Yes No
00 = Bell is an SAB Bell is an SCB
01 = User 1 Limited User 1 Unlimited
02 = Fire Signals All Fire Signals Set
03 = Silent 24hr Ccts Audible 24hr Ccts
04 = Enable Duress Disable Duress
05 = Invert Abort O/P Normal Abort O/P
06 = Set with LF Can’t Set with LF
07 = User Reset Engineer Reset
08 = Extended Format Fast Format
09 = Hi-Sec Engineer Lo-Sec Engineer
10 = Tamp User Reset Tamp Engr Reset
11 = Do Battery Test No Battery Test
12 = F.Exit Is Night F.Exit is Normal
13 = User Code + ENT User Code Only
14 = Show P.Set Info Show Time Only
15 = Dial Consecutively Dial Alternatively
16 = Set with AC Off No Set with AC Off
17 = Loud Chime Normal Chime
18 = Invert O/P 1 Normal O/P 1
19 = Invert Digi O/Ps Normal Digi O/Ps
20 = Online Keypad No Online Keypad
21 = Restore PID PID Alarms Only
22 = User Authorised No Authorisation
23 = Mimic Alm & Flt Mimic Alarm Only
24 = Monitor Off Hook Monitor Line Cut Only
25 = Answerphone Def. Normal Answer
29 = Keypad PA Silent Keypad PA Audible
30 = Sounder on Conf Sounder Immediate
31 = Bells on Conf Bells Immediate
32 = Conf After Entry Conf Dis’d on Entry
33 = Confirmation On Confirmation Dis’d
34 = Entry Kpd Lock Entry Kpd Enabled
35 = Tamp as Burg Tamp as Tamp
36 = Ent Conf on 2ccts Ent Conf on 1 cct
37 = Unconf Usr Reset Unconf Eng Reset
38 = Keypad PA On Keypad PA Off
Note: Options 26, 27, and 28 are intentionally
missing. The plug-on didgi modem:
1. Always sends Open/Close signals.
2. Only sends 24hr/Auxilliary or Tamper
signals when the system is set or part set.
30
0
Go To User Menu 1
32
B
View Location Text
33
C
Relearn Hardware
Clears the “RELEARN REQUIRED” / ”RESET
CONFIG” message and logs all devices on to
system.
34
49
TS590 Installation Manual Appendices
