PROPULSION MENU
eng 77
Analog
Speedometer
Displays the vessel speed with
a sweeping pointer. Two
different ranges are available;
0–80 or 0–120 as knots,
kilometers per hour, or miles per
hour.
42339
0
10
20
30
40
50
60
70
80
Speed(MPH)
PDL
Volts/Hours
Displays the total hours the
engine has run, the battery
current state of charge, and the
engine RPM.
Volts/Hours
[ EXIT ] [ NEXT ]
Hours
Battery
H
12.7
13.2
V
RPM
RPM
3250
36102
Boost
Pressure
Displays the engine RPM, the
vessel speed through the active
sensor, and the amount of
manifold pressure.
Boost Pressure
[ EXIT ] [ NEXT ]
SPEED
12.7
MPH
PDL
RPM
3250
36106
-2 +20
BAR
Trim Synch
(Dual Engine)
Displays a color band indicating
to increase or decrease the trim
to synchronize the engines trim
location.
[ EXIT ] [ NEXT ]
TRIM SYNCH
PORT
0.0
42340
Trim
3.2
STBD
To Next Page
