PUMP SERVICE MANUAL NUMBER 23

Page 9A-12 90-861326--1 MARCH 1999

Low Pressure Hose (Cooler-to-Pump)

REMOVAL

NOTE: Catch fluid that drains from hose, cooler and pump in a suitable container.

1. Loosen hose clamp and remove hose from fluid cooler.

75595

a-Hose

2. Loosen hose clamp and remove hose from back of pump.

72848

a-Hose Clamp

b-Hose
