VELVET DRIVE 5000A DOWN ANGLE TRANSMISSION SERVICE MANUAL NUMBER 23
Page 8B-8 90-861326--1 MARCH 1999
Transmission Shift Lever and Shift Cable Bracket
1. The lever has three holes as illustrated following. For use with Quicksilver shift cables,
the anchor stud is located in the middle hole.
73249
a
b
a-Shift Lever
b-Shift Cable Anchor Stud Location (For Quicksilver Shift Cables)
WARNING
Avoid serious personal injury or property damage caused by improper shifting.
Anchor stud for shift cable must be installed in the correct hole when using bracket
with four anchor location holes.
2. Be certain anchor stud is installed in the lower, front hole as shown in the illustration fol-
lowing.
74090
a
b
a-Cable Bracket
b-Shift Cable Anchor Stud Location (For Quicksilver Shift Cables)
