VELVET DRIVE 5000A DOWN ANGLE TRANSMISSION

SERVICE MANUAL NUMBER 23

90-861326--1 MARCH 1999 Page 8B-9

Shift Cable Adjustment

IMPORTANT: Velvet Drive Transmission Warranty is jeopardized if the shift lever pop-

pet ball or spring is permanently removed, if the shift lever is repositioned or changed

in any manner or if remote control and shift cable do not position shift lever exactly

as shown.

73248

a-Transmission Shift Lever

b-Poppet Ball Must Be Centered In This Detent Hole When Left-hand Propeller

Shaft Rotation Is Desired

c-Poppet Ball Must Be Centered In This Detent Hole When Right-hand Propeller

Shaft Rotation Is Desired

d-Poppet Ball Must Be Centered In This Detent Hole For Neutral Position

e-Install Shift Lever Stud In This Hole When Using Quicksilver Shift Cables
