Mercusys MW306R User Manual

2
Chapter 1
Chapter 1. Introduction
1. 1. Product Overview
The router integrates 3-port Switch, Firewall, NAT-Router and Wireless AP. Powered by 2x2
MIMO technology, the router delivers exceptional range and speed, which can fully meet
the need of Small Office/Home Office (SOHO) networks and the users demanding higher
networking performance.
1. 2. Product Appearance
1. 2. 1. Front Panel
The router’s LED is are located on the front panel.
Status Indication
Off Power is off.
On
Router/Access Point mode: The router is working normally.
Range Extender/WISP mode: The router is connected to a host or public Wi-Fi.
Flashing slowly Range Extender/WISP mode: The router is not connected to a host or public Wi-Fi.
Flashing quickly The system is starting up, upgrading firmware, or WPS connection is in progress.

Mercusys MW306R Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11d, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	-
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA-PSK, WPA2-PSK
Power source type	AC, DC
Product type	Tabletop router
Product color	White
Antennas quantity	3

Weight and Dimensions

Depth	115 mm
Width	147 mm
Height	34 mm
