Chapter 4

• Use Custom MAC Address - Select if your ISP requires you to register the MAC

address and enter the correct MAC address in this field, in case the ISP binds the

assigned IP address to the specific MAC address.

Note:

• You can only use the MAC Address Clone function for PCs on the LAN.

• If you have changed the WAN MAC address when the WAN connection is PPPoE, it will not take effect until the connection is

re-established.

4. 2. 4. LAN

1. Visit http://mwlogin.net, and log in with the password you set for the router.

2. Go to Advanced > Network > LAN.

3. Configure the IP parameters of the LAN and click SAVE.

• MAC Address - The physical address of the LAN ports. The value can not be changed.

• IP Address - Enter the IP address in dotted-decimal notation of your router (the default

one is 192.168.1.1).

• Subnet Mask - An address code that determines the size of the network. Normally

255.255.255.0 is used as the subnet mask.

Note:

• If you have changed the IP address, you must use the new IP address to log in.

• If the new IP address you set is not in the same subnet as the old one, the IP address pool in the DHCP Server will be

configured automatically, but the Virtual Server and DMZ Host will not take effect until they are re-configured.

4. 2. 5. IPTV/VLAN

1. Visit http://mwlogin.net, and log in with the password you set for the router.

2. Go to Advanced > Network > IPTV/VLAN.

3. Configure IPTV/VLAN settings if you want to enjoy IPTV or VoIP service, or if your ISP

requires VLAN tags.
