Chapter 4

• VPN Server IP/ Domain Name - Enter the VPN server’s IP address or domain name

provided by your ISP.

• MTU Size - The default MTU size is “1420” bytes, which is usually fine. It is not

recommended that you change the default MTU Size unless required by your ISP.

• Connection Mode

• Auto - In this mode, the internet connection reconnects automatically any it gets

disconnected.

• On Demand - In this mode, the internet connection will be terminated automatically

after a specified inactivity period (Max Idle Time) and be re-established when you

attempt to access the internet again.

• Manual - In this mode, the internet connection is controlled manually by clicking the

Connect/Disconnect button. This mode also supports the Max Idle Time function

as On Demand mode. Enter a maximum time (in minutes), the internet connection

can be inactive before it is terminated into the Max Idle Time. The default value is

15 minutes. If you want the internet connection remains active all the time, enter 0

(zero).

Note:

Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some applications

are visiting the internet continually in the background.

4. 2. 3. MAC Clone

1. Visit http://mwlogin.net, and log in with the password you set for the router.

2. Go to Advanced > Network > Internet and locate the MAC Clone section.

3. Configure Router MAC Address and click SAVE.

• Use Default MAC Address - Do not change the default MAC address of your router

in case the ISP does not bind the assigned IP address to the MAC address.

• Use Current MAC Address - Select to copy the current MAC address of the

computer that is connected to the router, in case the ISP binds the assigned IP

address to the MAC address.
