User Manual : Appendix II I/O Daughter-card Options
User Manual
340
With one Mykerinos board, it is only possible to use one DSD Input and Output channel. To have the full
range of 8 I/O channels, a second Mykerinos board is required to provide sufficient DSP power.
TASCAM TDIF
The TASCAM TDIF daughter card offers 24 channels of I/O over 3 Tascam TDIF connections. Connec-
tion is via three DB-25 connectors, One on the main card attached to the Mykerinos and two more on a
separate bracket connected via internal ribbon cable to the main card.
TASCAM TDIF I/O Option
A TASCAM TDIF format option bracket may be added to the ADAT I/O daughtercard and provides is
available for 8 channels of TDIF I/O. The TDIF bracket connects to a socket on the ADAT card only.
This daughter card cannot be used in multi-board systems (since it utilizes the HTDM connector).
