Dimension Drawing of EPT202 for Control Panel MountingDimension Drawing of EPT202 for Control Panel Mounting
Dimension Drawing of EPT202 for Control Panel MountingDimension Drawing of EPT202 for Control Panel Mounting
Dimension Drawing of EPT202 for Control Panel Mounting
9 Appendix
Fig. 8
142 [5,59]
236 [9,29]
278,3 [10,96]
58 [2,28]
Ø
7
[
Ø
,
2
8
]
177,2 [6,98]
200 [7,86]
269,4 [10,61]
252,4 [9,94]
58 [2,28]
Ø7x10 [.28x.39]
