Metaflex SDA-04DCB2 - Page 32

Installers manual 10.03.02-R03 (201058) EN SDA-04 (SW 5.xx) - SDA-04DCB2 (SW 22.00) Page 32 of 55
78
61
Locking at fault
1=Locked / 0=not locked
0/1
0
80
88
Pulse open pulse
close
1= enabled; 0=disabled
0/1
0
83
85
Emergency open
1..99 time till door closing in sec,
0=disabled
0/1..99
0
85
56
Fire configuration
0=Firedoor (high prioriry, user inputs
enabled)/ 1=escape door /
2=Firedoor (high prioriry) /
3=Firedoor (Lower priority)
4=as 0 with boost
5=as 2 with boost
6=as 3 with boost
0/1/2/3
0
86
81
Input door open
function
(input 12, 13)
0=normal / 1=open (input 12) /
2=fully open (12) of semi-open (13)
open / 3=emergency open (inp.12) /
4=door open or close depending on
position / 5= 1x press = semi-open,
2x press (during opening) = full open
0/1/2/3
4/5
0
88
-
Input 23
0=normal (feedback Lock) / 1=STOP
(AC) / 2=open without closing
timeout one-way (AC) / 3=open
without closing timeout (AC) /
4=stop locking interlock during T1 /
5= stop opening interlock during T1 /
6=See 4 with T2 / 7=See 5 with T2
0/1/2/3/4/
5/6/7
0
90
82
Doornumber
Communication address for LAN
module; 0=disabled
0/1..255
0
91
59
Interlock tim
Max. Time 2
e
door locked by
interlock (Doesn’t affect Lock input)
0 /
5..99 sec
0
92
84
Latch open
commando
Remembers open command when
interlock is activated.
0/1
0
