10 PRM 10 E | Version 1.05 | EN
Technical data
3 Technical data
3.1 Type plate
The name plate with the following data for identification as well as the CE mar-
king are attached to the motorized ring bending machine (Fig. 3).
Fig. 3: Type plate and CE marking of the motorized ring bending machine PRM 10 E
General data PRM 10 E
Shaft Diameter 30 mm
Roller diameter above 98 mm
Roller diameter below 118 mm
Speed 2,5 m/min
Dimensions [mm] 700 x 700 x 1400
Weight 230 kg
Engine power 1,1 kW
Mains connection 400 V
Frequency 50 Hz
Phases 3
