17
95-2009 DASH DISASSEMBLY
1
Unsnap radio/climate/instrument panel.
Disconnect the negative battery terminal to prevent an accidental short circuit.
3
Unsnap and remove small trim panel below steering column.
2
Move shift lever to first gear position.
4
Rotate panel counterclockwise to lift over steering column and remove.
5
Remove (3) 9/32" hex head screws to remove radio.
6
Continue to kit assembly.
CHEVROLET • EXPRESS VAN 2001-2002
GMC • SAVANNA 2001-2002
