18
95-2009 DASH DISASSEMBLY
1
Remove (2) 10mm bolts from panel below passenger dash airbag and remove
panel.
Disconnect the negative battery terminal to prevent an accidental short circuit.
3
Remove (2) 10mm bolts from below knee bolster under steering column
and remove panel.
2
Remove (2) 10mm nuts from inside center pocket between power outlets.
4
Unsnap and remove radio and instrument cluster panel. (May not be necessary
to completely remove radio and instrument cluster panel to access
radio.)
5
Remove (3) 9/32" bolts to remove radio.
6
Continue to kit assembly.
CHEVROLET • EXPRESS VAN 2003-2007
GMC • SAVANNA 2003-2007
