MI 3000 EasiPLUS Instrument description
13
Connector panel
1
3
2
> 550V
Figure 3.2: Connector panel
Legend:
1........Test connector.
Warning! Maximum allowed voltage between test terminals and ground is
600V! Maximal allowed voltage between test terminals is 550 V!
2........Power supply socket.
3........ Protection connector cover.
